| 光学 | photometrics |
| 光源 | cree 3w xml rgbw led/tian xin 3w | light source: | cree 3w xml rgbw led/tian xin 3w |
| 光束角度 | 15/25/45/60/90/120°（可选） | beam angle: | 15/25/45/60/90/120°（optional） |
| 显指 | >85 | ra | >85 |
| 亮度 | 10米距离6500 lux | output: | 6500 lux @ 10 meters |
| 效果 | key features |
| 混色 | r30 g33 b33 w24/w33pcs ww87pcs | color mixing: | r30 g33 b33 w24/w33pcs ww87pcs |
| 频闪 | 0-30 hz | strobe: | 0-30 hz |
| 调光 | 4种可选调光曲线 | dimming: | 4 dimming curve modes |
| 控制与程序 | control |
| 协议 | dmx/rdm | protocol: | dmx/rdm |
| dmx通道 | 7种通道模式可选 | dmx channels: | 7 |
| 内置程序 | 有 | built-in programs: | yes |
| 显示 | led数码显示 | display: | led 7dig |
| 输入电压及功率 | power |
| 输入电压和频率 | 100v-240v 50/60 hz | mains: | 100v-240v 50/60 hz |
| 功率 | 400w | consumption: | 400w |
| 电源与数据连接 | i/o |
| 电源连接 | 1.5m ip65 powercon 输入/输出 | power connections: | 1.5m ip65 powercon in/out |
| 数据连接 | 1.5m ip65 3-pin and 5-pin xlr 输入/输出 | data connections: | 1.5m ip65 3-pin and 5-pin xlr in/out for dmx |
| 外壳构造 | housing |
| 外壳 | 铝合金压铸 | material: | diecast aluminum |
| 表面处理 | 黑色亚光 | finish: | matte black |
| 防护等级 | ip65 | ip rating: | ip65 |
| 温度 | thermal |
| 散热 | 主动式 | cooling: | passive |
| 最高环境温度 | 45°c | max. ambient: | 45°c |
| 最低环境温度 | 零下20°c | min. ambient: | —20°c |
| 最高外壳温度 | 65°c | max. housing: | 65°c |
| 物理特性 | physical |
| 灯具尺寸: | l450*w450*h340mm | product dimensions: | l450*w450*h340mm |
| 包装尺寸 | 18kg | packing dimensions: | 18kg |
| 产品重量 | 14kg | packing weight: | 14kg |
| 配件 | misc / options |
| 安全绳 | 包含 | safety cord: | included |
| 灯钩 | 包含 | mounting clamp: | included |
| 旅行箱 | 不含 | touring case: | not included |
